Stabila 05820 LAR 300 rotary laser set with tripod and grade rod
General Information
Brand
STABILA
Number of Pieces
4
What's Included
LAR 300 rotary laser, REC 300 receiver with clamp, BST-S construction tripod, Hi/Lo elevation rod, hard case, 2 x D 1.5 V batteries, 2 x AA 1.5 V batteries
Country of Origin
Germany
UPC
089634058205
California Residents
Proposition 65 Warning
Return Policy
NCNR - Non-Cancellable / Non-Returnable
Part Number
05820
Product Type
Level
Physical Characteristics
Weight
16.51 kg
36.40 lb
Color
Yellow and Black
Details
Features
Fully automatic motor-driven rotary laser for horizontal applications – ready for immediate use with fast, self-leveling within 10 seconds. High leveling accuracy of ± 1/8 in @ 100 ft (± 0.1 mm/m).
Quality and precision, made in Germany.
Extremely tough thanks to the STABILA PROTECTOR system – perfect protection, even when the laser is dropped from a tripod at a height of up to 6 ft (1.8 m): just set up the tripod again, switch on and carry on measuring.
IP 65 - dust and waterproof.
Resistant to heat and cold from 14° F to 140° F (-10°C to +60°C).
Exceptionally easy to operate at just the touch of a button.
Large working area with set receiver – up to 2600 ft (800 m) diameter.
Correct heights quickly – digital read-out shows you exact distance from grade, arrows point you and down.
Receiver with visual and acoustic guidance as well as two displays.
5/8“ thread for attaching to a tripod.
Hard case for easy transport.
Compatible with commercially available machine controllers
In bricklaying – creating a perfect, level foundation.
In reinforced concrete construction – concreting foundations.
In carpentry and wood construction – adjusting the height of the ring beam.
In civil engineering and pipeline construction – for example, trenching.
In gardening and landscaping work – laying out garden areas, paths and paving
Quality and precision, made in Germany.
Extremely tough thanks to the STABILA PROTECTOR system – perfect protection, even when the laser is dropped from a tripod at a height of up to 6 ft (1.8 m): just set up the tripod again, switch on and carry on measuring.
IP 65 - dust and waterproof.
Resistant to heat and cold from 14° F to 140° F (-10°C to +60°C).
Exceptionally easy to operate at just the touch of a button.
Large working area with set receiver – up to 2600 ft (800 m) diameter.
Correct heights quickly – digital read-out shows you exact distance from grade, arrows point you and down.
Receiver with visual and acoustic guidance as well as two displays.
5/8“ thread for attaching to a tripod.
Hard case for easy transport.
Compatible with commercially available machine controllers
In bricklaying – creating a perfect, level foundation.
In reinforced concrete construction – concreting foundations.
In carpentry and wood construction – adjusting the height of the ring beam.
In civil engineering and pipeline construction – for example, trenching.
In gardening and landscaping work – laying out garden areas, paths and paving
Batteries
2 x D 1.5 V batteries, 2 x AA 1.5 V batteries
Voltage
1.5 V
Range
Self-levelling range ± : 5°
Accuracy
Levelling accuracy ± : 1/8 in @ 100 ft
Display Type
Digital Display
$2,302.04
